Shaft Seals

No filters active
Close filters

from to
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
No results were found for the filter!
230210-movet-blue-waterproof-wellendichtring
EAN 4061408124244 MOVET® Blue backseal 88x45 hygienic, blue, housing 208
from 13,81 €
Lieferbarkeit siehe Details

Shaft seals from Movet

Shaft seals are always used when a space between a shaft and a housing needs to be reliably sealed even at low pressure differences. The sealing effect is achieved by the geometry of the sealing edge of the oil seal and its mating surface. Shaft sealing rings from Movet are available either in the standard version made of high-quality NBR plastic or in a particularly hygienic, blue-coloured version made of TPU plastic. The sealing rings are usually available directly from stock. You can rely on the shortest delivery times and highest reliability in daily continuous use!

What do rotary shaft seals actually do?

A rotary shaft seal must perform two sealing tasks directly in use. On the one hand, the rotary shaft seals provide static sealing between the outer casing of the seal and the bore of the housing; on the other hand, the rotary shaft seal must also provide dynamic sealing with its sealing edge in the direction of the shaft surface. At least until the shaft comes to a standstill, because then the sealing in this area is also static. The static seal between the housing bore and the outer casing of the rotary shaft seal is achieved by an oversize of the outer diameter of the seal. The rotary shaft seal must be selected with a correspondingly precise fit to the subsequent installation space. To select the right oil seals in our Movet shop, it is best to use our practical filter!

How to install shaft seals

Installing shaft seals is not witchcraft, but care must be taken to ensure precise and careful installation in order to reliably prevent damage to the seals and leakage during operation. Cleanliness is the key to success when installing shaft seals. Even the smallest particles of dirt between the seal and the shaft can lead to leakage! Even pressure is the easiest way to press a shaft seal into the bore - ideally, use a pressure piece to distribute the pressure evenly over the seal. The sealing lip of the shaft seal rings must always face the medium to be sealed during installation. To ensure that the seal glides easily over the shaft, we recommend lubricating the shaft and seal with oil or grease before installation. We would be happy to advise you in a personal consultation on the subject of installing shaft seals. Just give us a call!

Buying shaft seals

In our Movet online shop you will find a large selection if you want to buy shaft seals. We have continuously expanded our range in recent years, so that we can provide the right sealing ring for almost every common shaft size. Buying oil seals from Movet is particularly easy and convenient in our online shop. First enter the shaft diameter, the material of the bearing insert, the housing type, the housing material and the area of application for the shaft seals in the search mask. Our system then automatically selects the most suitable portfolio for your needs. Many of our sealing rings are available for immediate delivery and will be at your site within just a few working days after receipt of your order.

Shaft seals shop from Movet

With our Movet shaft seal shop, we offer our customers a quick, easy selection of the right sealing rings for every need. Whether it's a classic sealing ring made of durable NBR plastic or our blue-coloured hygienic sealing rings for use in the food industry: thanks to intelligent filters, you are guaranteed to find the right product for your needs in our shaft seal shop. We have included all common shaft seals in our standard range, and most of the products are also available from stock with short delivery times. Should you not find the product you are looking for in our shop - no problem! In this case, simply contact us directly and we will be happy to deal with your enquiry immediately.

Shaft seal dimensions: It's all about the perfect fit!

When selecting the right sealing rings, every millimetre counts! Because only when the shaft sealing rings dimensions are perfectly matched to the shaft and the seat in the housing is a permanent seal without leakage guaranteed. In our shop, we have already provided our sealing rings with a filter system. Use the practical filter to define all known dimensions such as shaft diameter and housing type - and you will immediately receive an automatic product selection with the recommended dimensions. Of course, you can refine the product selection even further, for example by the material of the bearing insert, the product range or the area of application. In some cases, you may not be able to cover your needs perfectly with our standard products. For special seals, please contact our team of experts directly. We will be happy to work with you to design the perfect shaft seal for your individual needs!
